High quality and great service are the HG Belting values we offer our customers in many different industries
We constantly train and develop our employees to achieve premium customer service, technical advice and product knowledge.
Our management structure is fast tracked to avoid loss of communication. Our staff travel the world visiting our customers, to discuss wish lists, problems and requirements from shop floor, designers and senior managers. We believe sharing a problem is the easiest way to find a solution.
All our belts are custom made to order. We supply all the standard PTFE coated fabrics, but also have a large range of our specially designed coated fabrics. Together we decide what is best for our customers processes.
Check out the selection of products below and contact us to discuss your needs and interests.
The first and most important part of the conveyor belt is its material. All our belts are made from PTFE coated fabrics. The fabric is usually a glass weave, but can also be an aramid weave. For e.g. extra stability, release, wear-resistance and also for improved life time we can engineer the belt to specific requirements.
Laminated fabrics
Whether it is a PTFE topfilm on a standard fabric for better release or a 2-ply laminate for a smooth surface we can produce it to your demands in our factory.
Heavy belting fabrics
We have engineered numerous fabrics to fulfil all kinds of requirements like minimal elongation, improved stability, high moisture resistance.
Standard closed fabrics
We supply belts made from all available closed materials. From 10 x 1 inch sealing belts in 3 thou thickness, to 200 yards x 150 inch heavy duty belts up to 40 thou thickness
Standard mesh fabrics
Our mesh belts can be made to over 200 inches wide. Materials to choose from are PTFE coated glass, aramid or aramid/glass in mesh sizes 1×1 up to 8×8.
A good belt is important to give longevity of belt life, best possible air-flow and minimise mark off. This is why all our joints are constantly being reviewed and improved. Select your favorite or let us advise you:
Not all belts require an edge. Most closed belts are better without an edge, but some machines require a special edge. Mesh belts do need an edge reinforcement, usually simply a modified PTFE edge. Whatever edging you need on a PTFE belt, we can seal, sew or press it on to the belt.
Our high end step press gives the best sealed joints possible. Each press is engineered to fit our customers machinery and comes with our EasyWeldingSystem to ensure safe, quick and accurate work.
Our site teams can install your belt with this machine. But if you want to be independent and capable of quickly changing your belt, these presses are for sale or lease as well. Just ask us for all the options.
Our lightweight PTFE sealing presses are built to our customer’s individual requirements and vary in width from 600mm to over 3,300mm belt width. The presses operate using a vacuum to apply constant pressure on the joint. The complete cycle from start at ambient temperature to sealing temperature of 750 F, down to finish again will take about 40 minutes. All our presses are equipped with our EasyWeldingSystem to ensure safe, quick and accurate work.
Combining our press with a High-Temperature iron gives our customers a true 24/7 ability to carry out their own site joints and repairs without the need to wait for a site service team to arrive.
Supplies of welding accessories, such as sealing sets, or separate films and back-straps are available ex-stock all over the world.
Our architectural fabric press has a large sealing surface that helps with timely production of the long length seals that need to be made in this demanding industry. The press is easily and safely operated and can simply be ridden down to the next part of the project.
Combining our press with a High-Temperature iron gives our customers a true 24/7 ability to carry out their own site joints and repairs in whatever location.
Supplies of welding accessories, such as sealing sets, PFA / FEP films, or silicone sheets are available ex-stock.
“Just to let you know your team is doing an outstanding job servicing us. Thanks.”
Maintenance lead, carpet factory Georgia
“We are now sourcing laminated belts from HG Belting with low profile seams greatly improving our defect yield for impressions.”
Engineering manager, non-woven factory North Carolina
“We highly appreciate all the help we get in approving our belt and machine”
Maintenance engineering, flooring factory Georgia
HG Belting
HG Belting supplies high qualtiy PTFE belts made to our customers specific demands and presses for easily sealing the belts on site whilst also providing unrivalled customer service for all clients. Our teams are available 24/7 for questions, belts and installs. Find out how we can help you.
